LG LHD647 1000W 5.1 Channel Home Theatre System

LG LHD647 detailed description

1000W 5.1Ch System.
LG LHD647 Home Theatre has a 1000W total power output. With a 1000W total power output, you get one of the best loud sound systems in the market. And with surround speakers and a woofer, you get to have surround sound that ensures the sound is evenly spread around the room from your LG TV or other Smart TV such as the cheap 43″ Smart Android TV from Nobel.

Bass Blast Subwoofer.
LG LHD647 Home Theatre has a subwoofer that produces one of the best deep basses that you can feel in your bones. With the deep bass, you get a layer of excitement added when viewing the content or listen to music.

Wireless Connectivity.
LG LHD647 Home Theatre supports Bluetooth connectivity. With a Bluetooth connection, you get to stream all your favorite content directly to LG LHD647 Home Theatre without the need for a cable.

Features.

PHYSICAL.

• Size (W x H x D) mm – Main: 360 X 58 X 298.5
• Size (W x H x D) mm – Front Speaker: 250 x 1100 x 250
• Size (W x H x D) mm – Center Speaker: 260 x 93 x 73
• Size (W x H x D) mm – Rear Speaker: 88 x 122 x 81
• Size (W x H x D) mm – Subwoofer: 191 x 386 x 318

AMPLIFIER.

• CH: 5.1

POWER OUTPUT – Total: 1000W

• THD 10% – Front L/R: 167WX2
• (3Ω:sat/3Ω: subwoofer) – Center: 167W
• (3Ω:sat/3Ω: subwoofer) – Surround L/R: 167WX2
• (3Ω:sat/3Ω: subwoofer) – Sub-Woofer: 167W(Passive)

DESIGN (MAINSET).

• Uni-body (Tray): No
• Top & Bottom cabinet (Tray): No
• Front & Rear cabinet (tray): Yes

CONNECTIVITY.

• Wired (Ethernet): No
• HOME MENU.
• Cre-editable: No
• Home Dashboard: No
• Home Menu: Yes

IN & OUT.

• Front – Display: FLD
• Front – USB: 1
• Front – Mic – Mic In(φ6.3): 2
• Front – Audio In – Portable In: Yes

CONVENIENCE.

• Multi-tasking: No
• Smartphone Remote App: No
• Magic Remote Control: No
• SIMPLINK: No
• Instant tray open – Booting Time: No
• Warm booting: No
• Booting Time: No
• Loading Time: No
• Firmware update by network: No
• Speaker Level Trim: Yes
• Speaker Distance (channel delay): Yes
• Test-Tone: Yes
• Mute: Yes
• A/V Sync Delay(Audio Delay): Yes
• Dimmer: Yes
• Sleep: Yes
• Volume on TV: Yes
• USB Direct Recording: Yes
• External HDD Playback: No
• TV Sound (direct key) / TV Sound connect (Auto PWR on/off by optical): Yes / No
• Dynamic Range Control – On/Off Yes
• Meta Data Showing Gracenote (CD/Streaming/File): No
• Progress Bar: No
• Cinema zoom: Yes
• Thumbnail – Movie/Photo: Yes
• Wireless Speaker – 1:3 Speaker Built-in Type (Front / Subwoofer): No
• (Tx dongle Type) – 1:2 Speaker Built-in Type (Rear): No
• (Tx dongle Type) – 1:1 Rx module Type (Wireless Kit for rear): No
• (Tx dongle Type) – 1:1 Rx + Wireless Sub-woofer (3ch wireless): No
• (Tx dongle Type) – 1:1 RX for Subwoofer: No
• Bluetooth (Rx / Tx): Yes / No
• Karaoke – Mic Volume / Echo Volume: Yes
• Karaoke – Fanfare: Yes
• Karaoke – Scoring: Yes
• Karaoke – Real-Time Scoring: No
• Karaoke – Howling Canceller: Yes
• Karaoke – CD Voice Remover: Yes
• SOUND DSP.
• DSP: No

DISC & AV FORMAT.

• BD-ROM: No
• BD-R: No
• BD-RE: No
• Hybrid Disc (BD+DVD): No
• DVD(NTSC): Yes
• DVD(PAL): Yes
• DVD-R: Yes
• DVD-RW(Video/VR Mode): Yes / No
• DVD+R: Yes
• DVD+RW(Video mode): Yes
• DVD-RAM: No
• DVD-Audio: No
• Video CD/Super VCD: Yes / Yes
• Audio CD: Yes
• DTS-CD: No
• SACD: No
• CD-R/CD-RW: Yes
• MPEG2: Yes
• MPEG4 AVC (H.264): No
• SMPTE VC1 (VC-9): No
• DivX: No
• DivX HD: No
• Xvid: Yes
• MKV: No
• AVC Rec: No
• AVCHD: No
• M4V: No
• RMVB: No
• WMV: No
• FLV: No
• 3GP: No
• MPEG-1: No
• K3G: No
• MP4: No
• MOV: No
• VOB: No
• LPCM: LPCM
• Dolby Pro Logic II: No
• Dolby Digital: Yes
• Dolby Digital Plus: No
• Dolby TrueHD: No
• DTS: No
• DTS-HD High-Resolution Audio: No
• DTS-HD Master Audio: No
• DTS2.0+Digital Out: No
• MPEG 1/2 L2: Yes
• MP3 – ID3 Tag: Yes/Yes
• FLAC: No
• WMA: Yes
• AAC: No
• Graphics / Subtitle Format: 2bit / 8bit Sub-picture; Text-based Subtitle
• GUI/ Menu – Language: Option
• Video DAC: 148MHZ/12bit
• NTSC/PAL Hz: 60Hz / 50Hz
• NTSC/PAL Hz – Resolution: up to 1080p 24 / 60Hz
• VBI – WSS/GCMS-A/Closed Caption/Macrovision: Yes
• NTSC⇔PAL Conversion: Yes
• HDMI 1.4: No
• ARC: No
• Deep Color: No
• xvYCC: No
• Last Scene Memory: Yes
• Photo Zoom: No
• Video Enhancement: No

DISC (BD, DVD, CD) PLAYBACK SPECIFICATION.

• General – Screen Saver: Yes
• Auto Power Off: Yes
• Parental Lock: Yes
• BD – MHP-Like Interactivity: No
• BD – Simultaneous Playback of HD & SD Video Drip: No
• BD – BD ROM profile: No
• BD – Still Picture: No
• BD – Digital Cinema 4K upscaling: No
• DVD – 1080p Upscaling: Yes
• Trick Play – Fast Forward – DVD, CD-DA, MP3/WMA: Yes
• Trick Play – FastBack – DVD, CD-DA, MP3/WMA: Yes
• Trick Play – Fast Slow – DVD: Yes
• Trick Play – Reverse Slow: Yes
• Trick Play – Pause – DVD, CD-DA, MP3/WMA: Yes
• Trick Play – Pause – Forward Step – DVD: Yes
• Trick Play – Pause – Reverse Step: No
• Search – Title/Track – DVD, CD-DA, MP3/WMA: Yes
• Search – Chapter – DVD: Yes
• Search – Time – DVD: Yes
• Repeat Play – Title/Track – HDMV, DVD, CD-DA, MP3/WMA: Yes
• Repeat Play – Chapter – HDMV, DVD: Yes
• Repeat Play – A-B – HDMV, DVD(-VR): No
• Resume Stop – DVD, CD-DA, MP3/WMA: Yes
• Play Mode – Program – DVD, CD-DA, MP3/WMA: No
• Play Mode – Random – CD-DA, MP3/WMA: Yes
• Marker Search – 9 Points – DVD: No
• Marker Play – CD-DA, MP3/WMA: Yes

POWER.

• SMPS: Option
• Power Off Consumption: 0.5W ↓
• Power Consumption: 145W

RADIO.

• Tuner Type: PLL
• Tuning Up/Down: Yes
• Preset Up/Down: Yes
• Band FM / FM(RDS) / AM: Yes / No / No
• Preset Memory: 50 Station
• RDS (PS, PTY, CT, RT): No

SPEAKER.

• Front Speaker – SPL: 81dB
• Front Speaker – System: Closed Type
• Front Speaker – Woofer Unit: 3″ Paper
• Front Speaker – Impedance: 3Ω
• Front Speaker – Magnetic Shielding: Non-Shielded
• Rear Speaker – SPL: 81dB
• Rear Speaker – System: Closed Type
• Rear Speaker – Woofer Unit: 3″ Paper
• Rear Speaker – Impedance: 3Ω
• Rear Speaker – Magnetic Shielding: Non-Shielded
• Center Speaker – SPL: 79.0dB
• Center Speaker – System: Closed Type
• Center Speaker – Woofer Unit: 3″ Paper
• Center Speaker – Impedance: 3Ω
• Center Speaker – Magnetic Shielding: Non-Shielded
• Subwoofer – SPL: 83dB
• Subwoofer – System: Bass Reflex
• Subwoofer – Woofer Unit: 7″ Paper
• Subwoofer – Impedance: 3Ω
• Subwoofer – Magnetic Shielding: Non-Shield
